IEC60065 Short Test Pin Probe HT-I09 IEC61032 Figure 9 Test Probe 13 Metal Pin Tip Diameter Ф3

Name: IEC60065 Short Test Pin Probe HTI09 IEC61032 Figure 9 Test Probe 13 Metal Pin Tip Diameter Ф3
Brand: HeJin
Price: 1 USD

Buy cheap IEC60065 Short Test Pin Probe HT-I09 IEC61032 Figure 9 Test Probe 13 Metal Pin Tip Diameter Ф3 product

Brand Name : HeJin

Model Number : HT-I09

Certification : Third party calibration certificate/ CE(cost additional)

Place of Origin : China

MOQ : 1 Set

Price : Negotiatable

Payment Terms : T/T, L/C

Supply Ability : 30 set per month

Delivery Time : 20 days

Packaging Details : Aluminum Box

Standard : IEC61032 figure 9 Test probe13, IEC60950 figure 2B, IEC60335 and IEC60065

Metal pin tip diameter : Ф3 0 -0.05

Metal pin tail diameter : Ф4 0 -0.05

Metal pin length : 15 0 -0.1

Baffle diameter : Ф25±0.2

Baffle thickness : 4

Handle diameter : Ф10

Handle length : 20

Contact Now

Short Test Pin Probe HT-I09 IEC61032 Figure 9 Test Probe13 Metal Pin Tip Diameter Ф3

Standard of Short Test Pin Probe:

IEC61032 figure 9 Test Probe 13, IEC60950 figure 2B, IEC60335 and IEC60065.

Application of Short Test Pin Probe:

This pin is intended to verify the protection against access to hazardous live parts in class 0 equipment and class II equipment.

Feature of Short Test Pin Probe:

It can be used for enclosure protection test when open threaded hole of M6 at the end of the handle (connected with pull and push dynamometer).

Test Sample of Short Test Pin Probe:

Easily accessible enclosure live parts or mechanical parts.

Parameter of Short Test Pin Probe:

Model	HT-I09
Name	Short test pin probe
Metal pin tip diameter	Ф3⁰ _-0.05
Metal pin tail diameter	Ф4 ⁰ _-0.05
Metal pin length	15 ⁰ _-0.1
Baffle diameter	Ф25±0.2
Baffle thickness	4
Handle diameter	Ф10
Handle length	20

IEC60065 Short Test Pin Probe HT-I09 IEC61032 Figure 9 Test Probe 13 Metal Pin Tip Diameter Ф3
